Technical Details

• Package / Case TO-251-3 Short Leads, IPAK, TO-251AA
• Mounting Type Through Hole
• Triac Type Standard
• Configuration Single
• Operating Temperature -40°C ~ 125°C (TJ)
• Current - Hold (Ih) (Max) 25 mA
• Current - Gate Trigger (Igt) (Max) 25 mA
• Current - Non Rep. Surge 50, 60Hz (Itsm) 15A, 16A
• Voltage - Gate Trigger (Vgt) (Max) 1.3 V
• Supplier Device Package IPAK
• Current - On State (It (RMS)) (Max) 4 A
• Voltage - Off State 600 V
